FSD 40875 Metric Thickness Spacers
 |
|---|
| Part Number | Thickness |
|---|---|
| FSD 40875-01 | 2.00mm |
| FSD 40875-02 | 2.25mm |
| FSD 40875-03 | 2.50mm |
| FSD 40875-04 | 2.75mm |
| FSD 40875-05 | 3.00mm |
| FSD 40875-06 | 3.25mm |
| FSD 40875-07 | 3.50mm |
| FSD 40875-08 | 3.75mm |
| FSD 40875-09 | 4.00mm |
| FSD 40875-10 | 4.25mm |
| FSD 40875-11 | 4.50mm |
| FSD 40875-12 | 4.75mm |
| FSD 40875-13 | 5.00mm |
| FSD 40875-14 | 5.25mm |
| FSD 40875-15 | 5.50mm |
| FSD 40875-16 | 5.75mm |
| FSD 40875-17 | 6.00mm |
|
